CL-335 Adjustable Brass PAR36 Well Light by Corona Lighting
Material
Brass
Finish
Natural toning process. AB finish may vary due to the artistic process
AB-Antique Bronze
Housing
Stainless steel adjustable fixture, suspended inside a reversible PVC sleeve with both flat and angle-cut options on either end
Faceplate
Diecast brass louver-designed plate, tightened over housing. Drive-over rated up to 3,000 LBS.
Socket
Loose, top-grade screw-in terminal.
Light Source
12 Volt, PAR-36, 50W max
Gasket
Silicone “0†ring gasket on an adjustable fixture for watertight sealing.
Wiring
The fixture is prewired with a 5ft 18-2 SJT-W direct burial cord
Wire connectors sold separately.
Mounting
In-ground direct burial or concrete encasement. Use gravel for proper drainage.
Angle cut end required to be installed 3" above the ground
Warranty
Limited lifetime warranty on fixture against manufacturer's defects.
Led Options
Base: Spade Terminal, Beam spread: 45° FL
2700k - Rated hours: 50,000
L-ED36-6W-FL lumen: 610
L-ED36-10W-FL lumen: 800
Note
Voltage ranges for the fixture are:
LED lamps: 9-24V
Proper greasing and lubrication threaded parts are suggested for installation.
Adjustable fixture with aiming mechanism suspended in PVC sleeve.
A Remote 12 Volt transformer is required.
See transformers and accessories for a variety of options and choices.
